Eaton SPC0500480D2P Surge Protection Device
Eaton Surge Protection Device
SPECIFICATIONS
Clamping Voltage: 480 Delta V
Dimensions: 7.5 in L x 3.19 in W x 5 in H
Enclosure Type: NEMA 4X
Environmental Conditions: -40 to 140 deg F Operating/Storage Temperature, 5 to 95% Non-Condensing Operating Humidity
Indicator Type: Tri-Color LED
Modes of Protection: 550 L-G/640 L-L
Mounting Type: Side
Nominal Discharge Current: 20 kA
Number of Wires: 3W+G
Peak Surge Current: 50 kA
Series: SPC
Type: Type 2
Electrical Ratings: 480 Delta VAC
Frequency Rating: 50/60 Hz
Short Circuit Current Rating: 200 kA
Phase: 3
