Allen Bradley 20AE6P1A0AYNNNC0 PowerFlex 70 Inverter
The 20AE6P1A0AYNNNC0 is a PowerFlex 70 series inverter by Allen-Bradley /w/ 3ph 500...575VAC supply and 2.2kW, 3HP, 6.1A output.
IP20 rated enclosure, frame size B; 235mm x 172mm x 180mm (HxWxD), net weight of 4.1kg.
AFi systems are able to both supply and repair this drive and also other drives from within the PowerFlex 70 range.
In a breakdown situation we know that speed is key, so if your requirement is urgent give us a call for the fastest possible delivery.
All parts are supplied with our standard 2 year warranty.
20AE6P1A0AYNNNC0 Specifications
| Input Voltage (VAC) | 500...575 |
| Heavy Duty Power Output (kW) | 2.2 |
| Heavy Duty Power Output (HP) | 3 |
| Heavy Duty Output Current (A) | 6.1 |
| Input Phase | Three Phase |
| Ingress Protection Rating | IP20 |
| Drive Loop | Closed |
| Drive Logic | Positive |
| No. of Digital Inputs | 6 |
| No. of Analog Inputs | 2 |
| No. of Analog Outputs | 1 |
| No. of Relay Outputs | 2 |
| Height (mm) | 235 |
| Width (mm) | 172 |
| Depth (mm) | 180 |
| Weight (kg) | 4.1 |
