Parker SSD Drive 690PB/0040/230/3/0/0021/US/0/0/0/SHTTL/0
Parker 690PB/0040/230/3/0/0021/US/0/0/0/SHTTL/0 AC Drive with 3ph 220...240VAC Input and 3kW, 4HP, 16.5A Output.
690PB/0040/230/3/0/0021/US/0/0/0/SHTTL/0 Specifications
| Input Voltage (VAC) | 220...240 |
| Heavy Duty Power Output (kW) | 3 |
| Heavy Duty Power Output (HP) | 4 |
| Heavy Duty Output Current (A) | 16.5 |
| Normal Duty Power Output (kW) | 4 |
| Normal Duty Power Output (HP) | 5.5 |
| Normal Duty Output Current (A) | 16.5 |
| Input Phase | Three |
| Ingress Protection Rating | IP20 |
| EMC Filter | No |
| Drive Keypad | Yes |
| No. of Digital Inputs | 8 |
| No. of Analog Inputs | 4 |
| No. of Digital Outputs | 3 |
| No. of Analog Outputs | 3 |
