Vexta ASM66AA-T30 Stepper Motor
Vexta Stepper Motor
Product Line: VEXTA®
Motor Type: Closed Loop
Motor Frame Size: 2.36 in. sq.
Power Input: AC
Gear Ratio (X:1): 30 :1
Shaft/Gear Type: TH Geared
Shaft: Single
Electromagnetic Brake: Not Equipped
Resolution (Resolution Setting: 1000 P/R): 0.012 °/Pulse
Rotor Inertia (oz-in2): 2.20 oz-in2
RoHS Compliant: No
Safety Standards: UL, CSA, EN, CE
CE Marking: Low Voltage Directives, EMC Directives
Insulation Class: Class B (266ºF [130ºC]), UL/CSA: Recognized as Class A 221ºF (105ºC)
Insulation Resistance: 100 MΩ minimum when measured by a 500 VDC megger between the frame-windings.
Dielectric Strength: Sufficient to withstand the following for one minute: Frame-Windings 1.5 kV 50 or 60 Hz.
Ambient Humidity: 85% or less (noncondensing)
Operating Atmosphere: No corrosive gases, dust, water or oil.
