Karl Klein DNG 3-6 WS Blower
Karl Klein Blower
Karl Klein DNG 3-6 WS is a compact industrial blower designed for reliable air movement in a wide range of applications. It features a direct-drive centrifugal design and is optimized for consistent airflow with low noise output.
Model: DNG 3-6 WS
Airflow (Volume Flow Rate): 400–440 m³/h
Pressure Difference: ~320–350 Pa (depending on system resistance)
Inlet Diameter: 120 mm
Outlet Dimensions: 80 mm x 60 mm
Rotation Direction: Left-hand version
Construction: Sheet steel housing, powder-coated for durability
Weight: Approx. 4.05 kg
Motor Specifications – 2D56K50-2W, 2D56K40-2W
This blower is powered by a compact three-phase induction motor designed for continuous-duty operation in industrial environments.
Power Rating: 150 W
Voltage Range: 202–306 V / 350–530 V (3-phase)
Frequency: 50/60 Hz
Current Draw: Approx. 0.51–0.55 A (low voltage), 0.32–0.29 A (high voltage)
Number of Poles: 2 (high-speed motor)
Protection Class: IP54 (dust and splash protection)
Insulation Class: F
Cooling: External fan-cooled
