SLZ-16-100-KF-A-G-CV-CH Festo

FESTO SLZ-16-100-KF-A-G-CV-CH

Function shock absorber Cushioning self-adjustable Type of mounting Thread + lock nut Thread type M Thread diameter (metric) 10 mm Pitch 0,75 mm Thread length 30 mm Piston, nominal size 8 Stroke 8 Cushioning work per stroke 4 J Cushioning work per hour 24000 J Impact speed max. 3 m/s Impact force max. 400 N Reset force 15 N Residual energy max. 0,01 J Piston rod diameter 4 mm Diameter 8 mm Distance 16 mm Width 4 mm Length 77 mm Overall length 93 mm Minimum ambient temperature -10 °C Maximum ambient temperature 80 °C Reset time, short term 0,4 s Reset time, long term 1 s Permissible tightening torque 5 Nm Material of seals NBR-Elastomer Material of piston rod Steel with special properties Material of barrel/housing Steel Silicone status Free Product weight 0,04 kg Width across flats 13 mm
